Abstract

HyperFrames renders video from HTML, but the interesting software artifact is not the capture loop. It is the composition contract that makes a static document a seekable timeline. A root element carries `data-composition-id`, pixel size, and a compile-time `data-duration`. Timed visual children take `class="clip"`, a stable `id`, `data-start`, `data-duration`, and `data-track-index`. Tracks are a temporal occupancy rule, not paint order; same-track overlap is undefined and lint-fails. `data-start` may be seconds or a same-file clip-id expression. Visual clips must be direct children of the composition root, while `<video>` and `<audio>` are discovered by a flat query and may nest. Nested compositions travel through `<template>` and must share one id with the host slot and the paused timeline registry. This tutorial cites the public Apache-2.0 repository, the HTML schema, and the launch-video host. Capture details already covered in HeyGen's research post are treated as prior art.

An HTML composition contract for deterministic video

A video renderer that seeks HTML in headless Chrome is not a new idea. Remotion proved the shape; HeyGen’s HTML-to-video research post already documents the HyperFrames capture path (seek-don’t-play, HeadlessExperimental.beginFrame, FFmpeg JPEG flipbooks for <video>). This tutorial does not retell that pipeline. It documents the authoring contract that makes the pipeline possible: timing lives in HTML data-* attributes, not in a proprietary timeline JSON and not in wall-clock JavaScript.

The contract is public. HyperFrames is Apache 2.0. The HTML schema is at hyperframes.heygen.com/reference/html-schema; clip timing is at concepts/data-attributes. Agent-facing detail lives in skills/hyperframes-core/ at commit 2ca578f9455ca928ab168e7dd08a1a3a9d834788. We inspect those sources, plus the public launch-video host.

A sized root with locked duration

A composition is an HTML file. The top-level root sits in <body> with no <template> wrapper. It must be a real box with pixel width/height, and it must carry:

data-composition-id — unique id; must equal the animation registry key
data-width / data-height — authored frame size
data-start="0" on the top-level root (root_composition_missing_data_start otherwise)
data-duration — render length, not GSAP timeline length

A static root data-duration is read before scripts run, like frame size. A later setAttribute or --variables rewrite does not change the frame count. Clip-level data-duration is re-read from the live DOM. The root attribute may be omitted only when a finite duration is inferable (GSAP timeline, finite CSS/WAAPI, Lottie). Three.js, unbounded CSS/WAAPI, and a page with no animation signal require it. Lint: root_composition_missing_duration_source.

The public README registers a paused timeline on that same id:

<div id="stage" data-composition-id="launch" data-start="0" data-width="1920" data-height="1080">
  <h1 id="title" class="clip" data-start="1" data-duration="4" data-track-index="1">Launch day</h1>
  <script>
    const tl = gsap.timeline({ paused: true });
    tl.from("#title", { opacity: 0, y: 40, duration: 0.8 }, 1);
    window.__timelines = window.__timelines || {};
    window.__timelines.launch = tl;
  </script>
</div>

One paused timeline per composition, built synchronously at load. Do not play(). Do not nest a child GSAP timeline into the host; HyperFrames seeks nested compositions independently.

Clips: class, window, and parentage

A clip is any element with data-start, data-duration (where required), and data-track-index. Visual timed elements (<div>, <img>, <section>, …) also need class="clip". Without the class, the runtime keeps the element visible for the whole composition and ignores its start/duration. <video> visibility is owned by the media runtime; <audio> has no visual lifecycle.

The visibility window is inclusive: a clip shows while start ≤ t ≤ start + duration, so the last frame holds the resolved end state.

Parentage is the silent failure. Visual class="clip" nodes must be direct children of the composition root. A clip wrapped in an extra <div> is not registered, so its timing is ignored and it stays on screen. Put wrappers inside the clip, or animate the clip itself. That rule is in skills/hyperframes-core/references/data-attributes.md at the pinned commit. Media is the exemption, covered below. Duplicate <video>/<img> ids across assembled files render blank: the producer injects frames by getElementById.

Tracks occupy time; CSS paints

data-track-index is a temporal occupancy lane, not a z-stack. Two clips on the same track must not overlap. hyperframes lint flags the collision; the render is undefined. Paint order is CSS z-index. A clip on track 10 is not “in front of” track 1.

Put sequential scenes on one visual track. Put an intentional overlap — a crossfade, a caption over B-roll — on a second track. The launch video puts voiceover on track 0 and scenes on 1; skill docs often put audio at 10+ so visual lint stays readable. Either works if same-track ranges do not collide. Legacy aliases: data-layer → data-track-index, data-end → data-duration.

Start times as numbers or clip ids

A numeric data-start is seconds from the start of this composition. A non-numeric value is a same-file clip-id expression: intro means “when intro ends”; intro + 0.5 is a gap; intro - 0.5 is an overlap.

<video id="intro" data-start="0" data-duration="4" data-track-index="0"
       src="./intro.mp4" muted playsinline></video>
<section id="result" class="clip" data-start="intro - 0.5" data-duration="3" data-track-index="1">
  The result
</section>

References do not cross composition boundaries. The target must have a known duration. Cycles are rejected. A value that parses as a number is always absolute seconds. Negative offsets require a different track.

Nested compositions as template transport

A host slot is itself a clip. data-composition-src names a file; paths resolve from the project root. The host’s data-composition-id must equal the inner file’s data-composition-id and the window.__timelines["<id>"] key — no -mount/-slot suffix. Per-file lint will not catch a rename; render then waits 45s for a timeline that never registers and captures static frames.

The runtime fetches the file, DOMParsers it, and clones only <template> contents — <head> is discarded. Inlined CSS is rewritten to [data-composition-id="<id>"] S. A class on the inner root then fails to match; lint subcomposition_root_styled_by_class flags it. Prefer #root, which the scoper special-cases.

Host data-duration is the slot window, not the child timeline length. A short child holds its last frame. A short slot goes blank (subcomposition_blanks_before_host). Prefer gsap.fromTo inside sub-comps: the host re-seeks on each visibility, and from() records start state at registration.

Media is discovered flat

<video> and <audio> work at any nesting depth, including inside a sub-comp <template>. The runtime does a flat querySelectorAll("video, audio") and rebases local data-start by ancestor composition starts. Do not call play(), pause(), or set currentTime. Videos are muted and playsinline; sound is a separate <audio> even when the file is the same.

The remaining constraint is timelines, not placement. A sub-comp timeline cannot reach host-root elements. If media lives on the host, drive its motion on the main timeline at global time, or keep the media inside the sub-comp that animates it. data-media-start offsets into the source file; for nested hosts the schema’s child-timeline offset is data-playback-start.

Author rules that keep a seek honest

The renderer samples time; it does not play. Visual state at time t must be a function of t alone. Banned for visual state: Date.now(), performance.now(), unseeded Math.random(), render-time network, input state, repeat: -1. Finite repeats use floor, not ceil (gsap_repeat_ceil_overshoot).

Do not tween display or raw visibility on a .clip — the framework owns clip lifecycle. GSAP autoAlpha and zero-duration tl.set(..., { visibility }) are allowed only on non-clip wrappers inside a clip. Do not gsap.set later-scene clips at page load; they are not in the DOM yet. Motion belongs on a paused, seekable runtime registered to the composition id.

A public host, not a demo card

heygen-com/hyperframes-launch-video documents a 49.77s, 1920×1080, 30fps project: one root plus 17 sub-composition files. Sequential scene slots share data-track-index="1"; the root timeline is registered empty and paused. Voiceover is a host-page <audio> whose data-duration matches the root. Modular pattern: scenes in compositions/*.html, continuous audio at the host, one visual track unless a seam needs overlap.

<div id="master-root" data-composition-id="master"
     data-width="1920" data-height="1080" data-start="0" data-duration="49.77">
  <div id="c-glass-intro" data-composition-id="glass-intro"
       data-composition-src="compositions/glass-intro.html"
       data-start="0" data-duration="18.24"
       data-width="1920" data-height="1080" data-track-index="1"></div>
  <!-- further slots on the same track, adjoining in time -->
  <script>
    window.__timelines = window.__timelines || {};
    window.__timelines["master"] = gsap.timeline({ paused: true });
  </script>
</div>

The project’s README notes that hyperframes lint still reports overlapping clips and GSAP tween overlap as known punch-list items. The contract is checkable; a production host can still violate it and render.

Checking the contract

npx hyperframes lint is the static gate (missing ids, same-track overlap, unregistered timelines, duration-source, CSS/GSAP transform fights). npx hyperframes check boots Chrome once for runtime errors, layout boxes, contrast, and optional motion assertions. Sub-compositions need snapshot --at midpoints: the three mount pitfalls (styles outside <template>, id mismatch, class-styled root) pass per-file lint and fail only when assembled.

Limits

We did not invent HTML-as-video. Remotion, WebVideoCreator, and the HeyGen research post already cover seek-driven capture; this paper does not re-measure beginFrame, JPEG flipbooks, or font inlining. We do not claim pixel-identical output across OS images, a lint-clean launch-video host, equal use of every animation adapter, or that class="clip" is required on <video>. We do not document Studio UI, cloud pricing, or any private emitter of HyperFrames HTML.

The finding is narrower: a seekable video can be a static HTML document whose timing, occupancy, and nesting rules are declared in attributes the linter can check and the renderer can seek.
